| General specifications |
| Switching function |
Normally open (NO) |
| Output type |
NPN |
| Rated operating distance |
40 mm |
| Installation |
non-flush |
| Output polarity |
DC |
| Assured operating distance |
0 ... 32.4 mm |
| Actual operating distance |
36 ... 44 mm |
| Reduction factor rAl |
0.3 |
| Reduction factor rCu |
0.28 |
| Reduction factor r304 |
0.75 |
| Reduction factor rBrass |
0.38 |
| Nominal ratings |
| Operating voltage |
10 ... 30 V DC |
| Switching frequency |
0 ... 180 Hz |
| Hysteresis |
typ. 5 % |
| Reverse polarity protection |
reverse polarity protected |
| Short-circuit protection |
pulsing |
| Voltage drop |
≤ 2 V |
| Operating current |
0 ... 200 mA |
| Off-state current |
0 ... 0.5 mA |
| No-load supply current |
≤ 20 mA |
| Operating voltage indicator |
LED, green |
| Switching state indicator |
LED, yellow |
| Functional safety related parameters |
| MTTFd |
1510 a |
| Mission Time (TM) |
20 a |
| Diagnostic Coverage (DC) |
0 % |
| Approvals and certificates |
| EAC conformity |
TR CU 020/2011 |
| Protection class |
II |
|
Rated insulation voltage |
253 V |
|
Rated impulse withstand voltage |
4000 V |
| UL approval |
cULus Listed, General Purpose |
| CCC approval |
CCC approval / marking not required for products rated ≤36 V |
| Ambient conditions |
| Ambient temperature |
-25 ... 85 °C (-13 ... 185 °F) |
| Storage temperature |
-40 ... 85 °C (-40 ... 185 °F) |
| Mechanical specifications |
| Connection type |
Connector M12 x 1 , 4-pin |
| Housing material |
PA |
| Sensing face |
PA |
| Housing diameter |
|
| Degree of protection |
IP69K |
